Form factor: 2U Rack Mount
Front drive bays: 24 LFF SAS/SATA or 48 SFF SAS/SATA
Rear drive bays: Optional 12 E3.S 1T Gen5 NVMe, 6 SFF Gen4 NVMe/SAS/SATA, or 4 LFF SAS/SATA
Dedicated boot device: Optional hardware mirrored dual M.2 NVMe SSDs (internal only) or direct attached dual M.2 NVMe SSDs
Storage controller: 1 to 4 16/32-port with 8 GB cache (consume expansion slots) and optional Intel® Virtual RAID on CPU (Intel VROC)
Network controller: Up to 2 PCIe full-height half-length and 2 OCP 3.0 controllers, up to 200 Gb/s 2-port (consume expansion slots)
Expansion slots: Up to 8 full-height half-length PCIe Gen5 slots and 2 OCP 3.0 slots with 2 processors installed
Memory slots: 24 DDR5 memory slots (12 per procrssor) for 4 TB maximum
Processor family: Single or dual 4th or 5th generation Intel Xeon Scalable processors
Accelerators: Up to 1 GPU or FPGA (full-height half-length and under 75 W; consumes expansion slot)
Power specifications: 2 HPE Flexible Slot (Flex Slot) Power Supplies of up to 2200 W per Power Supply
System cooling: 5 system dual-fan modules with N+1 rotor redundancy
Security: TPM 2.0, iDevID, Silicon Root of Trust, logical Configuration Lock, Secure Boot, Secure Start, optional controller-based Secure Encryption, optional Self-Encrypting Drives, optional Secure Erase, optional lockable security bezel, optional HPE Server Security Optimized Service
Infrastructure management: HPE iLO 6 Standard, HPE iLO 6 Advanced upgradable with license; HPE Compute Ops Management (subscription included) or optional HPE OneView (download required)
Warranty: 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
Dimensions: 87.50 x 448.00 x 812.80 mm (3.44 x 17.63 x 32.00 in)
