Improved performance and scale: supports up to 396 Gpbs bandwidth, 9 member switch stacking, 32K MAC table, improved ARP, ACL, IPv4/v6 unicast and multicast scale.
High availability: Hot swappable dual power supplies and dual fans, mLAG for link level aggregation and redundancy.
6 built-in 10/25 G uplink ports offers competitive platform TCO.
Comprehensive L3 routing and MPLS features, IPv4/v6 support, L3 multicast support.
Enhanced security: Trusted Platform Module (TPM) and secure boot, support industry-standard MACsec 256 encryption for end-to-end data link layer security on all ports.
Standard CLI and Smart Management Center (SmartMC) embedded and ready to use, delivering network visibility, management, and operations at no additional cost.
Power consumption: Idle: Single AC: 14W, Dual AC: 16W; Single DC:18W, Dual DC: 25W
Full Load: Single AC: 53W, Dual AC: 56W; Single DC: 54W, Dual DC: 61W
Input voltageAC: 90V to 264V, DC: -36V to -72V
Latency: GE: < 5 µs, 10GE: < 3 µs, 40GE: <1.2µs
Routing capabilities: RIP, OSPF, ISIS, BGP, DHCP, VRRP, VRRP PE, ECMP, BFD, IPv6
Switching capacity: 348 - 396 Gbps, depending on model
Stacking capabilities: 9 member IRF stack
Throughput: 259 - 295 Mpps, depending on model
Memory and processor: Arm 1.6GHz dual core CPU
4 GB SDRAM; 4GB flash, 3MB packet buffer
Power supply name: PSU: 1+1, hot swappable, 1 min PSU required
Fans: 1+1, hot swappable
Operating temperature: 23°F to 122°F (–5°C to 50°C)
Management features: HPE IMC; Smart MC, command-line interface; web browser; SNMP manager
Warranty: Limited lifetime warranty. See the warranty duration guide.
