High-performance modular Layer 3 switches with BGP, EVPN, VXLAN, VRF, and OSPF with robust security, MACsec encryption, and QoS while delivering up to 28 Tbps in non-blockling bandwidth.
High availability with industry-leading VSX and redundant power supplies and fans.
Full density HPE Smart Rate (1/2.5/5GbE) multi-gigabit, 60W PoE, and SFP+ modules.
High-speed, non-blocking 1GbE, 10 GbE, 25 GbE, 40 GbE, and 100 GbE with intelligent monitoring, visibility and remediation with the Network Analytics Engine
Manage via single pane of glass with HPE Aruba Networking Central across wired, wireless, and WAN.
Dynamic Segmentation enables enhanced security and simple access for users and IoT.
Input voltage: 110-127 / 200-240 VAC (power supplies sold separately)
Ports: 10 I/O module slots, maximum, depending on model
Switching capacity: Up to 28 Tbps, depending on model and configuration
Throughput: Up to 20 Bpps, depending on model and configuration
Memory and processor: Management module: Quad Core ARM Cortex™ A72 @ 1.8GHz, 16GB DDR4 ECC memory, 32GB eMMC Flash memory
Line card: Dual Core ARM Cortex™ A72 @ 1.8GHz, 4GB DDR4 memory
Line card: 8MB shared packet buffer memory(R0X38A, R0X39A, R0X40A, R0X41A, R0X42A, R0X43A), 32MB shared packet buffer memory (R0X44A, R0X45A)
PoE capability: Available IEEE 802.3af, 802.3at, 802.3bt PoE support, depending on model and configuration
Management features:
HPE Aruba Networking AirWave
HPE Aruba Networking Central Network Management
HPE Aruba Networking Switch Multi-Edit Software
HPE Aruba Networking CX Mobile App
Command-line interface
SNMP v2c/v3
RMON
Weight: 53.5 kg, maximum, depending on model (118.2 lbs, maximum, depending on model)
Dimensions: 52.88 x 44.26 x 44.85 cm, maximum, depending on model (20.8 x 17.5 x 17.7 in, maximum, depending on model)
Warranty: Limited lifetime warranty. See the warranty duration.
