Performance:
Switch fabric capacity (full duplex): 576Gbps
Forwarding rate: 800Mpps
Power:
100 - 240 VAC 50/60 Hz
Optional Power Supplies:
550W AC hot swappable with IO/PS airflow, adds redundancy to S3248T-ON
550W AC hot swappable with PS/IO airflow, adds redundancy to S3248T-ON
Power Cords:
C13 to NEMA 5-15, 3M
C13 to C14, 2M
Ports:
48x RJ45 10M/100M/1G auto-sensing ports, 4x 10G SFP+ ports, 2 integrated rear 100GbE QSFP28 uplink ports
Out-of-band management port (10/100/1000BASE-T)
USB (Type A) port for configuration via USB flash drive
MicroUSB (Type B) console port (MicroUSB to USB connector cable included)
RJ45 console port with RS232 signaling (RJ-45 to female DB-9 connector cable included)
Dimensions & Weight:
Dimensions: 43.50 mm x 434 mm x 400 mm (1.71 in x 17.09 in x 15.75 in)
Weight: 6.99 kg (15.4 lb); PSU 0.79 kg (1.75 lb)
Security:
RADIUS, TACACS+, 802.1x
Regulatory:
Emissions & Safety
Australia/New Zealand: ACMA RCM Class A
Canada: ICES Class A; cUL
China: CCC Class A; NAL
Europe: CE Class A
Japan: VCCI Class A
USA: FCC Class A; NRTL UL; FDA 21 CFR 1040.10 and 1040.11
Eurasia Customs Union: EAC Germany: GS mark
Product meets and safety standards in many countries inclusive of USA, Canada, EU, Japan, China.
For more country-specific regulatory information and approvals, please see your Dell representative.
RoHS
Product meets RoHS compliance standards in many countries inclusive of USA, EU, China, and India. For more country-specific RoHS compliance information, please see your Dell representative.
EU WEEE
EU Battery Directive REACH
Energy
Japan: JEL
Management:
CLI, SNMP, REST APIs
Other Switching:
Enterprise SONiC Distribution by Dell Technologies
Dell SmartFabric OS10
Open networking
Environmental Operating Conditions:
Power supply efficiency: 80% or better in all operating modes
Maximum thermal output (BTU/hr): 349.06
Power consumption max (watts): 212
Operating temperature: 0° to 45°C (32 to 113°F)
Operating humidity: 8% to 90% (RH), noncondensing
Storage temperature: –40° to 65°C (-40 to 149°F)
Storage relative humidity: 5% to 95%, noncondensing
