PROCESSOR - 2 SOCKETS
1st Generation Intel Xeon Scalable processors - Up to two Intel Xeon Scalable processors, up to 14 cores per processor
2nd Generation Intel Xeon Scalable processors - Up to two Intel Xeon Scalable processors, up to 28 cores per processor
MEMORY
Memory Type
Registered (RDIMM)
Load-Reduced (LRDIMM)
Memory Speed
Gen 1 Intel Xeon Scalable Processors - 16 DDR4 DIMM slots, RDIMMS/ LRDIMMS speeds up to 2666MT/s
Gen 2 Intel Xeon Scalable Processors - 16 DDR4 DIMM slots, RDIMMS/ LRDIMMS speeds up to 2666MT/s
Maximum Memory Capacity
RDIMM: 512GB
LRDIMM: 1TB
Supports registered ECC DDR4 DIMMs only
STORAGE CONTROLLERS
Internal controllers: PERC H330 / H730P / H740P / HBA330 / Software RAID (SWRAID) S140
Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB, 240 GB
External PERC (RAID): H840
External HBAs (non-RAID): 12 Gbps SAS HBA
DRIVE BAYS
Up to 4 or 8 x 3.5" SAS/SATA (HDD/SSD) max 80TB
Up to 16 x 2.5" SAS/SATA (HDD/SSD) max 61TB
POWER SUPPLIES
495W, 750W, 1100W hot-plug PSU; Gold efficiency
450W Cabled AC PSU
CHASSIS
Form factor: Tower or rack, 5U
Chassis max depth: 594.82 mm
BEZEL
Optional security bezel
EMBEDDED / AT-SERVER
iDRAC9 with Lifecycle Controller
iDRAC Direct
iDRAC REST API with Redfish
CONSOLES & MOBILE
OpenManage Enterprise (available soon)
OpenManage Essentials
OpenManage Power Center
OpenManage Mobile
INTEGRATIONS
OpenManage integrations:
Microsoft® System Center
VMware® vCenter™
BMC Software
CONNECTIONS
OpenManage connections:
Nagios & Nagios XI
Oracle Enterprise Manager
HP Operations Manager
IBM Tivoli Netcool/OMNIbus
IBM Tivoli® Network Manager
CA Network and Systems Management
TOOLS
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs
iDRAC Service Module
OpenManage Server Administrator
OpenManage Storage Services
SECURITY
TPM 1.2/2.0 optional
Cryptographically signed firmware
Hardware Root of Trust
Secure Boot
System Lockdown
System Erase
I/O & PORTS
2 x 1GbE LOM
9 x USB (5 x USB 2.0, 4 x USB 3.0), dedicated IDRAC Direct Micro-USB
Video card: VGA
Up to 5 PCIe Gen 3 slots
GPU
1X NVIDIA NVS 310
1X NVIDIA Quadro P4000
SUPPORTED OPERATING SYSTEMS
Canonical® Ubuntu® LTS
Citrix® XenServer®
Microsoft Windows Server® with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi
